Home Commercial Refrigeration Equipment Walk-In Unit Coolers / Evaporators Low Profile Electric Defrost Unit Cooler- Walk-In, Low Profile, Electric Defrost, 230v, 6 FPI, 1 Fan, R404A 4,900 BTU - R448A/R449A 5,600 BTU at -20°F

HTPG-Russell

Unit Cooler- Walk-In, Low Profile, Electric Defrost, 230v, 6 FPI, 1 Fan, R404A 4,900 BTU - R448A/R449A 5,600 BTU at -20°F

PART RL6E049DDA
MFG RL6E049DDA
Calculating price...
QUANTITY

About this item

  • Embossed aluminum housing is lightweight and durable
  • Fan sections are baffled to prevent short cycling of air
  • End panels slide out for easy serviceability from the front or ends of the unit
  • Mounts flush to the ceiling to maximize headroom and space

Russell All-Temp were the original low profile unit coolers that established the industry standard as being the all-purpose design for walk-in coolers, freezers and other applications. We've taken these unit coolers to the next level with the release of the Next-Gen All-Temp models. The units feature a new fan guard design and deep draw venturi to achieve optimal airflow and easy access for serviceability.

Instruction/Installation Manual
Instruction/Installation Manual
Catalog
Catalog
Brand HTPG-Russell
Voltage Rating 208 to 230 V
Amperage Rating 0.5 A
Power Rating 1125 W
Frequency Rating 60 Hz
Phase 1 ph
BTU Rating 4900 Btu/hr
CFM Rating 775 cfm
Connection Type NPT
Connection Size 3/4 in
Coil Type Aluminum Fin, Copper Tube
Refrigerant Type R-404A
Number of Fans 1
Number of Speeds 2
Motor Type ECM
Fins per Inch 6 FPI
Mounting Type Ceiling, Flush
Material Aluminum
Temperature Rating -20 to 10 deg F
Dimensions 27-1/8 in L x 18-1/8 in W x 16-3/4 in H
Additional Information Electric Defrost Style, 20 A Maximum Overcurrent Protection Device, 15 A Minimum Current Ampacity, 3/8 in Liquid, 5/8 in Suction
