Home Air Distribution Products Ventilation Bathroom Fans Broan® Bathroom Exhaust Fan, ENERGY STAR®, 50-110 CFM

Broan-Nutone

Broan® Bathroom Exhaust Fan, ENERGY STAR®, 50-110 CFM

PART AE50-110DC
MFG AE50110DC
Calculating price...
QUANTITY

About this item

  • Bathroom Exhaust Fan
  • Powerful ventilation reduces humidity to quickly eliminate fogged mirrors and manage moisture, so your vision will always be clear and your surroundings will always be comfortable
  • Retrofit installations can be done entirely from the room side, no attic access required, this means a faster, easier installation
  • Flex DC fans reduce air leakage by up to 50% compared to competitive models, resulting in better home performance via blower door tests and reducing cold and warm air backdrafts
  • Plug-in, permanently lubricated, brushless DC motor engineered for continuous operation
  • Can be installed in a wall if mounted 8 ft or more above the floor
  • Dynamically balanced centrifugal blower wheel for quiet, efficient performance
  • Low RPM for quiet operation
  • FlexFlow technology, select between 50 cfm, 80 cfm or 110 cfm

Broan® AE50110DC Flex DC series exhaust bath fan, ENERGY STAR offers easy, room side installation, with "no attic access required". Ceiling-mounted ventilation fan features foldable mounting ears and EZ duct connector for easy installation. New duct damper technology provides a tighter seal, resulting in reduced warm and cold air backdrafts. This energy efficient fan operates at a selectable cfm range of 50 to 110 at a quiet operation of <0.3 to 0.9 sones.

Instruction/Installation Manual
Instruction/Installation Manual
Catalog
Catalog
Specification Sheet
Specification Sheet
Video Link
Video Link
Brand Broan-Nutone
Series Flex DC
Voltage Rating 120 VAC
Amperage Rating 0.3 A
Frequency Rating 60 Hz
Power Rating 3.4 to 14.9 W
Mounting Type Ceiling, Wall
Grille Size 11-1/2 x 12 in
Duct Size 4 in
Motor Type Brushless DC
CFM Rating 50 to 110 cfm
Coverage Area 105 sq-ft
Noise Rating 0.3 to 1.4 sones
Overall Length 9-1/4 in
Overall Width 10 in
Overall Height 5-3/4 in
Housing Material Steel
Housing Finish Galvanized
Housing Color White
